Vertical Chain Hoist

Get a Price/Quote

MOQ : 1 Piece

Vertical Chain Hoist Specification

Shelf Life
Long; robust construction ensures durability

Reusable
Yes

Water Proof
Yes, corrosion-resistant finish

Application
Lifting, rigging, and material handling in industries such as construction, manufacturing, shipping, and warehouses

Number Of Layers
Single body/standard steel construction

Function
Vertical lifting of heavy loads/material by chain mechanism

Disposability
Reusable

Tensile Strength
High; as per rated load capacity (varies by model)

Length
Customizable or as per requirement

Features
High load capacity, secure locking mechanism, ergonomic design for easy handling, corrosion-resistant coating, heavy-duty construction

Material
Alloy steel/forged steel

Color
Yellow and red (as per image)

Size
Available in various models (e.g., 1 ton, 2 ton, 5 ton as required)

Weight
Varies as per model; refer to manufacturers datasheet

Surface Finish
Powder coated and painted for rust resistance

Capacity
From 1 ton up to 10 tons (customizable)

Operation
Manual chain-driven

Rotation
360-degree swiveling lifting eye

Type
Vertical Chain Hoist (Plate Lifting Clamp)

Safety Mechanism
Equipped with locking lever for secure lifting

Jaw Opening
Standard and wide jaw openings available

Temperature Range
Suitable for use from -20C to +100C

Handle Type
Ergonomically designed lever handle

Vertical Chain Hoist Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
500 Pieces Per Day

Delivery Time
1-5 Days

Main Domestic Market
All India

About Vertical Chain Hoist

Charmi Enterprise is trading in top notch quality vertical chain hoist. It is a type of hoisting apparatus that raises large things using a chain. Construction and industrial applications frequently use it. Our offering is attached to the hand crank-driven pulley system that holds the chain in place. To prevent binding, the chain is fed through a series of guide rails. A hook is used to fasten the thing to be lifted to the chain. The object is then raised by pulling the chain through the pulley mechanism. Vertical chain hoist is a very practical invention that can be used to move large machinery and other objects with the least amount of labour and effort.

Versatile Lifting Capabilities

The Vertical Chain Hoist accommodates a broad load range, from 1 to 10 tons, making it suitable for various industrial applications. Users can select from multiple models or customize capacity and length based on specific job site requirements. Its sturdy alloy or forged steel body ensures long shelf life and dependable performance under demanding conditions.

Enhanced Safety and Ergonomics

Equipped with a secure locking lever and an ergonomically designed lever handle, this hoist prioritizes operator safety and comfort. The 360-degree swiveling lifting eye delivers excellent directional flexibility during use, while the corrosion-resistant, powder-coated finish provides ongoing protection in harsh environments, ensuring reliability across multiple sectors.

FAQ's of Vertical Chain Hoist:

Q: How does the manual chain-driven operation of the Vertical Chain Hoist work?

A: The Vertical Chain Hoist operates through a manual chain mechanism. By pulling the hand chain, users activate the internal gears which lift or lower heavy loads vertically. The process is smooth and requires minimal effort thanks to the ergonomic lever handle.

Q: What types of jaw openings are available for this hoist, and how do I choose the right one?

A: This hoist comes in both standard and wide jaw opening options. Standard jaws are suitable for general lifting tasks, while wide jaws accommodate thicker or irregular plates. Selection depends on the material thickness and specific requirements of your application.

Q: When should I use a vertical chain hoist with a locking lever safety mechanism?

A: A vertical chain hoist with a locking lever should be used whenever secure vertical lifting of heavy materials is crucial, such as in construction, manufacturing, or warehouse operations. The locking lever ensures the load remains securely held during lifting, preventing accidental release and enhancing safety.

Q: Where can the Vertical Chain Hoist be used?

A: This hoist is versatile and suited for use in industries like construction, manufacturing, shipping, and warehouses. Its durable, corrosion-resistant build and broad temperature range make it reliable indoors and outdoors, even in demanding conditions.

Q: What is the process for adjusting the hoist length and load capacity?

A: The hoist's length and load capacity can be customized according to user requirements at the time of order. Consult the manufacturer or supplier with your specifications, and select the appropriate model based on rated load capacity and application needs.

Q: How does the corrosion-resistant finish benefit industrial users?

A: The powder-coated and painted surface provides excellent resistance to rust and corrosion, ensuring the hoist remains durable and reliable even in harsh working environments. This enhances the product's longevity, reduces maintenance needs, and ensures consistent performance.
